Absolute Maximum Ratings
| Parameters | Symbol | Range | Unit |
| Analog supply voltage | VDD | -0.3 to 6.0 | V |
| Operating temperature | -40 to +125 | ℃ | |
| Storage temperature | -50 to +150 | ℃ | |
| Junction temperature | +150 | ℃ | |
| ESD susceptibility | HBM | 4 | kV |
Note: Exceeding the absolute maximum rating may cause permanent damage, and prolonged operation at the above absolute maximum rating may affect the reliability of the device.
Electrical Characteristic
Table 1. Operating Characteristics (VS = 5.0 Vdc, TA = 25°C unless otherwise noted)
| Parameters | Symbol | Min | Typ | Max | Unit |
| Supply Voltage | VS | 4.75 | 5 | 5.25 | Vdc |
| Supply Current | Io | — | 3 | mAdc | |
| Offset (0°C to 85°C) @ VS = 5.0Volts | Voff | 0.44 | 0.5 | 0.56 | Vdc |
| Full Scale Output (0°C to 85°C) @ VS = 5.0V | VFSO | 4.44 | 4.5 | 4.56 | Vdc |
| Full Scale Span (0 ℃ to 85 ℃) @ VS=5.0V | VFSS | 3.88 | 4 | 4.12 | Vdc |
Continue Table 1. Operating Characteristics (VS = 5.0 Vdc, TA = 25°C unless otherwise noted)
| Parameters | Symbol | Min | Typ | Max | Unit |
| Accuracy (0°C to 85°C) | — | — | — | 2.5 | %VFSS |
| Response Time | tR | — | 2.5 | — | ms |
| Warm-Up Time | — | — | 100 | — | ms |
| Offset Stability | — | — | 0.25 | — | %VFSS |
