Electrical parameters
| Characteristic | Symbol | Min | Typ | Max | Unit |
| Vs=5.0V (MCP-H20-A series) | VS | 4.75 | 5.0 | 5.25 | VDC |
| Vs=3.3V (MCP-H20-B series) | VS | 3 | 3.3 | 3.6 | VDC |
| Working current | Io | — | 3 | mADC | |
| Accuracy（0℃ to 85℃） | — | — | — | 1.5 | %VFSS |
| ADC resolution | RESADC | — | 24 | — | bit |
| DAC resolution | RESDAC | — | 12 | — | bit |
| Response time | tR | — | 2.5 | — | ms |
| Warm-up time | — | — | 100 | — | ms |
| ESD Protection | — | — | 2 | — | kV |
Output parameters
MCP-H20-A series (Power Supply Voltage: 5.0V)
| Characteristic | Symbol | Min | Typ | Max | Unit |
| Min pressure offset (0℃ to 85℃) | Voff | 0.44 | 0.5 | 0.56 | VDC |
| Full-scale output (0℃ to 85℃) | VFSO | 4.44 | 4.5 | 4.56 | VDC |
| Full-scale span (0℃ to 85℃) | VFSS | 3.88 | 4 | 4.12 | VDC |
MCP-H20-B series (Power Supply Voltage: 3.3V)
| Characteristic | Symbol | Min | Typ | Max | Unit |
| Min pressure offset (0℃ to 85℃) | Voff | 0.055 | 0.1 | 0.145 | VDC |
| Full-scale output (0℃ to 85℃) | VFSO | 3.055 | 3.1 | 3.145 | VDC |
| Full-scale span (0℃ to 85℃) | VFSS | 2.91 | 3 | 3.09 | VDC |
